Raymarine B45 600W Bronze Thru-Hull Transducer with Fairing Block

Raymarine B45 600W Bronze Thru-Hull Transducer with Fairing Block

The B45 is our smallest and most economical, dual-frequency, bronze, stem transducer. The included fairing streamlines the transducer and increases the performance—even at higher speeds.

Features:

  • Depth and fast-response water-temperature sensor
  • 600 W
  • Dual-frequency element:
    • 50 kHz with a wide 45° beamwidth for depth performance to 353 m (1,200')
    • 200 kHz with a 12° beamwidth for depth performance to 206 m (700')
  • Excellent performance and sensitivity in a small housing
  • Bronze-stem housing with high-performance fairing for optimal performance at speed
  • Bronze transducer housing

Code Image Product Details Enquire
E26019-PZ
Raymarine B45 600W Bronze Thru-Hull Transducer with Fairing Block
Instrument Connectors
Make an Enquiry

Weight: 2.5 kg (5.5 lb.)

Recommended Boat Length: Up to 9 m (30’)

Hull Material: Fiberglass or wood

Hull Deadrise: Up to 26° with fairing

Acoustic Window: Urethane

Hole Diameter: 22 mm or 7/8"

Includes: High-performance fairing and mounting hardware
