Raymarine CP200 Sidevision Module
The CP200 CHIRP SideVision® Sonar expands your underwater horizon with crystal-clear, bank-to-bank displays of fish, bait and underwater structure.
The CP200 delivers side scan sonar imagery so close to reality we call it Visionality™. Raymarine CHIRP signal processing delivers high resolution and excellent long-range performance. Identify objects and see fish even further, out to 600-feet on each side! Side scan performance using two high-performance transducer arrays with dedicated CHIRP sonar channels. Independently adjustable transducer arrays enable anglers to preset their SideVision® transducer angle for either shallow or deep-water applications. Left and Right sonar images up to 600' / 183m either side of the boat.
Connect the CP200 with Raymarine LightHouse II powered multifunction displays, including aSeries, cSeries, eSeries, the NEW eS Series and the gS Series systems.
Combine the CP200 CHIRP SideVision sonar module with the CPT-200 SideVision transom transducer. Engineered for high performance CHIRP sonar the CPT-200 transducer is perfectly matched to the CP200’s CHIRP transceiver.
The CPT-200 transom mount CHIRP SideVision sonar array has independently adjustable port and starboard arrays for shallow, mid or deep-water scanning It includes a rugged patented kick-up guide that ensures the transducer can be easily returned to its original position in the even the transducer kicks up after striking an object or debris.
NOTE: this transducer is not suitable for mounting on vessels where the transom is aft of the propellers
