CTEK CS One Battery Charger
Charging any battery just got a whole lot simpler with the CTEK CS ONE. Its revolutionary APTO™ (Adaptive Charging) technology does all the thinking for you – you don’t even have to worry about which clamp goes where! This is the easiest charger you’ll ever use. Add in a dedicated app control to unlock additional features and you’ve got the most advanced charger available today. Super simple. Super smart.
Features:
RECOND option to restore and recondition lead-acid batteries.
WAKE UP option to revive seemingly dead lithium and lead-acid batteries.
12V Supply to support the battery during service work and retain contact power to the vehicle during battery replacement / removal.
Advanced Settings to monitor charger voltage & amperage.
Can be left safely connected for long periods during maintenance charging.
New durable design to make it easy to handle, with unique mounting system on the back for quick connection to CS accessories.
|
Battery capacity |
3–180 Ah |
|
Battery capacity CEC-400 |
3–180 Ah |
|
Charging category |
AC charging |
|
Back current drain* |
Corresponding to less than 1.5 Ah/month |
|
Battery voltage |
12 V |
|
Battery chemistry |
Lead acid; Lithium-ion |
|
Ambient operating temperature |
-30 °C to +50 °C |
|
Cooling |
Natural convection |
|
Input |
220–240 VAC, 47–63 Hz, 1.2 A |
|
Output |
12 V, 8.0 A |
|
Start voltage |
1.5 V lead-acid battery types. 1.5 V LiFePO₄. |
|
Frequency |
50 Hz |
|
Ripple** |
Less than 4 % |
|
Connectivity |
BLUETOOTH® LE 5.1 |
|
Battery types |
12 V:; WET; MF; Ca/Ca; AGM; EFB; GEL; LiFePO₄ |
|
Temperature compensation |
Built in charge voltage compensation according to ambient temperature. |
|
Compliance |
ETSI EN 300 328; RED; EN 61000-6-3; EN 61000-6-1; ETSI EN 301 489-1; ETSI EN 301 489-17; EN 60 335-2-29; EN 60335-1; SS-EN ISO 13732-1:2008 |
|
Enclosure material |
Plastic |
|
Rated voltage (Input) |
230 V |
|
Degree of protection |
IP65 |
|
Mains cable length (input) |
1.4 m |
|
App support |
CTEK App for Android and IOS |
|
Dimensions (L x W x H) |
235 x 88 x 52 mm |
|
Net weight (unit with cables) |
0.675 kg |
|
User interface |
LED symbols; Smartphone display (free of choice) |
|
Detachable charging cable length (ouput) |
2 m |
|
Packaging size (L x W x H) |
288 x 178 x 55 mm |
|
Warranty |
5 years |
|
Warranty, info |
Limited Warranty |
|
Power plug type |
Type G |
