Relaxn Fixed Pedestal

Relaxn Fixed Pedestal

HTML Editor - Full Version

• Heavy-duty cast aluminium base with 6 x 8mm countersunk mounting holes.
• Friction clamping top.
• Moulded nylon cup insert provides a smooth swivel performance.
• 228mm (9") anodised finish base.
• 72.6mm (2 7/8") satin finish post.
• Powder coated aluminium swivel.
• 360° rotation with a centrally located locking handle easy to reach with left or right hand.
• Standard mounting pattern.

Code Image Product Details Enquire
293776
Relaxn Fixed Pedestal
With Swivel 710mm
293786
Relaxn Fixed Pedestal
Seat Slide & Swivel 160mm
293794
Relaxn Fixed Pedestal
Seat Slide & Swivel 72mm
293809
Relaxn Fixed Pedestal
Seat Slide & Swivel 72mm

PART NO293776
Height: 760mm
Base: Dia. 228mm
Post: Dia. 72.6mm (2-7/8")

PART NO. 293786
HEIGHT: 160mm
Base: Dia. 228mm
Post: Dia. 72.6mm (2-7/8")
