Jabsco 2in Clutch Pump 1B Pulley, 12v Electric Clutch

Jabsco 2in Clutch Pump 1B Pulley, 12v Electric Clutch

Constructed from marine quality bronze and stainless steel for ruggedness and reliability.

Easy to service and maintain.

Inexpensive to buy and operate.

Will tolerate abrasive wear (this may affect performance - seek advice from your distributer).

Handles hard and soft solids without clogging.

Can pump in either direction.

Will not airlock.



Code Image Product Details Enquire
50270-2211
Jabsco 2in Clutch Pump 1B Pulley, 12v Electric Clutch
2", 12VDC - 1B Section
Make an Enquiry

Body Materials: Bronze head, Cast Iron bearing housing

Impeller: Neoprene or Nitrile

Wearplate: Replaceable

Shaft Material: Stainless steel

Seal: Carbon/ceramic mechanical type

Bearings: Twin single row, ball type

Port Type: 2" Flange or 2" BSP to BS21 (DIN2999)

Clutch Type: Electro-magnetic 12 or 24Vdc

Pulley: 178mm (7") 'A' or 'B' section

Weight: 12.2 (kg) 27 (lb)

Port Type: 2" BSP to BS21 (DIN2999)

Impeller: Neoprene

Coil: 12v dc

Pulley: 1B Section

Amp Draw: 3 (amp)
