Raymarine PM111LH-W 2kw CHIRP Pocket Mount Transducer
Get more coverage under your boat with Airmar’s unique wide beam, high frequency Chirp-ready PM111LH-W transducer. The high band operates across a frequency range of 150 to 250 kHz and has a fixed 25° beam for all frequencies. The high frequency band results in superior resolution. The constant wide beam width provides twice the coverage under the boat and excellent fish arches on the display compared to most high frequency narrow beam transducer options.
The high wide is the ideal choice for both inshore and pelagic fishing, where resolution and maximum coverage under the boat are essential down to 500'.
The low frequency band and 2 kW of power also provides great deeper water performance. Get the best of both worlds with Airmar’s dual frequency Chirp-ready PM111LH-W transducer with wide beam coverage.
*All wide beam products come with a 2M pigtail off the transducer. Pair with a CHIRP Transducer Extension Cable (3, 5 or 10M) for a complete transducer installation.
Features
- Depth and fast-response water-temperature sensor
- 2kW power for great deep-water performance to 6000’ (1828m)
- High wide beam width provides more coverage under the boat for detecting fish in the upper water column
- Recommended boat size: above 40' (12m)
- Hull Type: Fiberglass, wood and metal
- Compatible with CP470/570
Style: Pocket/Keel
Cable Length: 6' (2m)
Monitors: Depth/temperature
Material: Urethane
Compatible Hull Materials: Solid fiberglass
Transmit Power: 2kW
Frequency/Beam width:
- Low/High: 38-75 kHz (25°-16° beam
- Low/Medium: 80-130 kHz (13° to 8° beam)
- Low/High-Wide: 150-250 kHz (25° beam)
Depth:
- Low: 6000'(1828m)
- High-Wide: 800'(243m)
NOTE: Also available as in-hull (R111LH) and external (R109LH) mounts
